- Affordable Sparset, with the included Relay.
- Great coverage by Wi-Fi 802.11 b/g/n Standard.
- Universal application possibilities thanks to the three available operation modes: Wireless Router (AP), Wireless Client (STA), as well as both at the same time (AP + STA)!
- Thanks to a powerful 80MHz processor and a large 1MB memory, can be operated with the esp8266 01 also Autonomous!
- Communication with Sensors via two GPIO Pins possible!
When the module on the WIFI module is unplugged, USB to TTL module RX, TX, GND pins were connected to the module RX, TX, GND pin, IN +, IN- 5V power supply, then the module can be used as a USB Relays to use, scalability.
ESP8266 module has a timeout
mechanism, when the phone for some time (the default 180S) did not give
instructions to the module, the module will kick off the phone, the
computer can send AT + CIPSTO = to modify this time (Time range 0-7200),
such as: AT + CIPSTO = 3600
Mobile phone equipped with WiFi module
Mobile phone and WiFI module
equipped with the same router, through the mobile phone APP to control
the relay; this mode, the transmission distance depends on the signal
Operating voltage: DC5V
Product size: 45 * 28mm
Communication: WIFI (ESP8266 module) Transmission distance: the maximum transmission distance of 400m (open environment, mobile phone equipped with WIFI module)
Serial communication parameters: 9600,8,1,0,0
Load: 10A/250VAC 10A/30VDC, the relay pull 100,000 times
